Hot Wire Anemometry
A. A. Lab Systems is manufacturing Hot-Wire Anemometry systems for more than 23 years. Our Hot-Wire Anemometer systems (and Hot-Film Anemometry as well) are used for aeronautics and Fluid Dynamics research throughout the world, by major industrial companies, research and educational institutions.
Our Anemometry systems were designed for most professional applications. We
put all of our efforts in designing systems for customers who care about excellent Signal to Noise ratio, Ultra low temperature drift, and versatility to any type of Hot-Wire probe or Hot-Film probe, regardless of their manufacturers. Our anemometers also work with very complex vorticity probes with or without common ground conductor. All of our anemometers also work with SenFlex® probe arrays made by Tao systems inc.
Each of our models is designed for a diffeerent application and system setup.
The AN-1003 is most suitable for Aeronautics laboratories, where the data acquisition system and software already exists and only the Analog interface is needed. It offers compatability to any existing data acquisition system while maintaining excellent performance and signal quality.
The AN-1005 is a small compact system, with Built-in Data acquisition system. This low cost system was mainly designed for application where up to 4 channels can be used and price/space are important, like educational applications as well as small research applications or verification of PIV measurements.
The AN-2000 is a fully automated remote system. This multi-channel system was designed for application where the whole measurement and calibration process, as well as the data acquisition must be automated. The AN-2000 Hot- Wire Anemometer can output linearized data at extremely high throughput rates, making this system ideal for flow control applications. The systems also offers many unique features as Sine Wave Response real-time analyzer, Built-in Digital oscilloscope and calibrated low-pass filters with the same phase response (and delay) on all channels.
Comparision table
Product model | Number of channels | CCA Option |
Bridge Ratios | Analog Outputs | Computer interface | Filtering | Sampling Rate |
Optical Isolation |
AN-1002 | Up to 2 |
Yes |
4 |
T.O.B & Amplifier Output
|
External A2D card |
Low-Pass x 12 Freq. |
N/A
|
|
AN-1003 | Up to 10 |
Yes |
4 |
T.O.B & Amplifier Output
|
External A2D card |
Low-Pass x 12 Freq. |
N/A
|
|
AN-1005 | Up to 4 |
Yes |
4 |
T.O.B & Amplifier Output
|
USB2/ Parallel |
Low-Pass x 12 Freq. |
Up to
1 MHz
for all channels |
Built-in
|
AN-2000 | Up to 16 |
Yes |
4 |
T.O.B & Amplifier Output
|
USB2 & DRV11 & RS-232 |
Low-Pass x 512 Freq. |
Up to 500 KHz. per channel
|
Built-in
|
All of our Hot-Wire Anemometry systems can be calibrated using our CAL-2000 Digital Air-Speed Calibrator. The CAL-2000 is a stand alone system capable of producing air velocity from 1-70 m/Sec.
